N and AN inch Lock Nuts

1/4	N and AN inch Lock Nuts Previous HM Lock Nut With Locking Pin Next MB(L) Lock Washers +86-15051683850

Product Description
Product Model

Description

N and AN inch Lock Nuts

Thread size		Principal dimensions		Designations
	Threads per inch			Lock nut	Appropriate locking device
G		d₃	B
mm		mm
9.931	32	19.177	5.817	N 00	W 00
11.913	32	22.352	8.204	N 01	W 01
14.884	32	25.527	8.204	N 02	W 02
16.866	32	28.702	8.992	N 03	W 03
19.837	32	35.052	9.779	N 04	W 04
24.613	32	39.827	10.566	N 05	W 05
29.794	18	44.577	10.566	N 06	W 06
34.95	18	52.527	11.379	N 07	W 07
39.7	18	57.277	11.379	N 08	W 08
44.882	18	64.414	11.379	N 09	W 09
49.962	18	68.402	12.954	N 10	W 10
54.788	18	75.54	12.954	N 11	W 11
59.944	18	80.289	13.741	N 12	W 12
64.719	18	85.852	14.554	N 13	W 13
69.875	18	92.202	14.554	N 14	W 14
74.498	12	98.552	15.342	AN 15	W 15
79.68	12	105.689	15.342	AN 16	W 16
84.836	12	112.039	16.129	AN 17	W 17
89.586	12	118.389	17.729	AN 18	W 18
94.742	12	125.552	18.517	AN 19	W 19
99.517	12	131.902	19.304	AN 20	W 20
104.699	12	138.252	19.304	AN 21	W 21
109.855	12	145.39	20.091	AN 22	W 22
109.855	12	135.077	20.091	N 022	W 022
119.786	12	155.702	20.904	AN 24	W 24
119.786	12	144.602	20.904	N 024	W 024
129.692	12	171.577	22.479	AN 26	W 26
129.692	12	155.702	22.479	N 026	W 026
139.624	12	180.315	24.079	AN 28	W 28
139.624	12	165.227	24.079	N 028	W 028
149.555	12	195.402	24.867	AN 30	W 30
149.555	12	181.102	24.867	N 030	W 030
159.614	8	204.927	26.441	AN 32	W 32
159.614	8	190.627	26.441	N 032	W 032
169.139	8	200.152	27.254	N 034	W 034
169.139	8	219.989	27.254	AN 34	W 34
179.476	8	209.677	28.042	N 036	W 036
179.476	8	230.327	28.042	AN 36	W 36
189.789	8	220.802	28.829	N 038	W 038
189.789	8	240.64	28.829	AN 38	W 38
199.314	8	250.165	30.429	AN 40	W 40
199.314	8	239.852	30.429	N 040	W 040
219.151	8	260.477	32.004	N 044	W 044
219.151	8	279.527	32.004	N 44	W 44
239.827	6	290.652	34.392	N 048	PL 48
258.877	6	309.702	35.966	N 052	PL 52
279.502	6	330.327	38.354	N 056	PL 56
299.339	6	360.502	39.954	N 060	PL 60
319.075	6	381.127	42.316	N 064	PL 64
338.811	5	400.177	45.491	N 068	PL 68

DSQ has well-knows as one of the credible suppliers of n and an inch lock nuts. With many warehouse and qualified distributors spread around the world, our company can not only assure you the quality of this n and an inch lock nuts but also great after-sale service and timely delivery of our products. Waiting for your contact with our agent!
